TL431QDBZT
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 TL431 Tape & Reel (TR) ACTIVE (Last Updated: 3days ago) voltage reference device 1mA 37V 92ppm/C ±2.2%
PDF
/
Buying Options
Total Price: USD $0.73
Unit Price: USD $0.7304
≥1 USD $0.7304
≥10 USD $0.6556
≥100 USD $0.622336
≥500 USD $0.511104
Inventory: 1136
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Number of Pins 3
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Tolerance ±2.2%
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient 34 ppm/°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.95mm
Base Part Number TL431
Pin Count 3
Number of Outputs 1
Output Voltage 36V
Output Type Adjustable
Max Output Current 100mA
Supply Voltage-Min (Vsup) 2.495V
Number of Channels 1
Trim/Adjustable Output YES
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Max Output Voltage 36V
Voltage - Output (Min/Fixed) 2.495V
Max Input Voltage 37V
Reference Type Shunt
Min Output Voltage 2.5V
Temp Coef of Voltage-Max 92 ppm/°C
Current - Cathode 1mA
Dimensions
Height 1.22mm
Length 2.92mm
Width 1.3mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
