TL431BQD
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 TL431 Tube ACTIVE (Last Updated: 6days ago) voltage reference device 700muA 37V 92ppm/C ±0.5%
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.616
≥1 USD $0.616
≥10 USD $0.54912
≥100 USD $0.520846
≥500 USD $0.427856
≥1000 USD $0.399934
≥3000 USD $0.353426
Inventory: 1483
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Current - Cathode 700μA
Temp Coef of Voltage-Max 92 ppm/°C
Min Output Voltage 2.5V
Reference Type Shunt
Max Input Voltage 37V
Voltage - Output (Min/Fixed) 2.495V
Max Output Voltage 36V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Number of Channels 1
Supply Voltage-Min (Vsup) 2.495V
Max Output Current 100mA
Output Type Adjustable
Output Voltage 36V
Number of Outputs 1
Pin Count 8
Base Part Number TL431
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Voltage References
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 34 ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Tolerance ±0.5%
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Weight 72.603129mg
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
