TL431BIPE4
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 PDIP Nickel/Palladium/Gold (Ni/Pd/Au) OUTPUT VOLTAGE ADJUSTABLE FROM 2.495V TO 36V voltage reference device 700muA 37V 125C 0.5%
PDF
/
Buying Options
Total Price: USD $3.91
Unit Price: USD $3.910135
≥1 USD $3.910135
≥10 USD $3.688815
≥100 USD $3.480006
≥500 USD $3.283033
≥1000 USD $3.097198
Inventory: 1365
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.62mm
Technical
Voltage Reference 2.495V
Current - Cathode 700μA
Min Output Voltage 2.5V
Reference Type Adjustable, Shunt
Max Input Voltage 37V
Min Input Voltage 2.495V
Voltage - Output 36V
Max Output Voltage 36V
Current - Output 100mA
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Number of Channels 1
Temperature Grade INDUSTRIAL
Max Output Current 100mA
Output Voltage 2.495V
Number of Outputs 1
Pin Count 8
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position DUAL
Technology BIPOLAR
Subcategory Voltage References
Additional Feature OUTPUT VOLTAGE ADJUSTABLE FROM 2.495V TO 36V
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 34 ppm/°C
ECCN Code EAR99
Termination Through Hole
Number of Terminations 8
Pbfree Code yes
JESD-609 Code e4
Tolerance 0.5%
Physical
Weight 440.409842mg
Number of Pins 8
Surface Mount NO
Package / Case PDIP
Alternative Model
