TL431BIDRE4
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 TL431 Tape & Reel (TR) ACTIVE (Last Updated: 1week ago) voltage reference device 700muA 37V 92ppm/C ±0.5%
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.72434
≥1 USD $0.72434
≥10 USD $0.683338
≥100 USD $0.644665
≥500 USD $0.608173
≥1000 USD $0.573748
Inventory: 1445
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Current - Cathode 700μA
Temp Coef of Voltage-Max 92 ppm/°C
Voltage - Output (Max) 36V
Min Output Voltage 2.495V
Reference Type Shunt
Max Input Voltage 37V
Max Output Voltage 36V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Max Output Current 100mA
Output Type Adjustable
Output Voltage 36V
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 8
Base Part Number TL431
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Voltage References
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 34 ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Tolerance ±0.5%
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 72.603129mg
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
Alternative Model
