TL4050C25QDBZT
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 TL4050 Tape & Reel (TR) Nickel/Palladium/Gold (Ni/Pd/Au) voltage reference device 65muA 2.5V 41muVrms 50ppm/C
PDF
/
Inventory: 8704
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Number of Pins 3
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Tolerance ±0.5%
JESD-609 Code e4
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient 50ppm/°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.95mm
Base Part Number TL4050
Pin Count 3
Number of Outputs 1
Output Voltage 2.5V
Output Type Fixed
Max Output Current 15mA
Trim/Adjustable Output NO
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Max Output Voltage 2.5V
Reference Type Shunt
Min Output Voltage 2.5V
Temp Coef of Voltage-Max 50 ppm/°C
Current - Cathode 65μA
Noise - 10Hz to 10kHz 41μVrms
Dimensions
Height Seated (Max) 1.12mm
Length 2.92mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
