REF5040IDR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 REF5040 Tape & Reel (TR) ACTIVE (Last Updated: 6days ago) voltage reference device 10mA 18V 3muVp-p 3ppm/C
PDF
/
Buying Options
Total Price: USD $12.89
Unit Price: USD $12.8877
≥1 USD $12.8877
≥10 USD $10.57445
≥100 USD $10.24385
≥500 USD $9.91325
≥1000 USD $9.58265
Inventory: 1485
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Weight 75.891673mg
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Tolerance ±0.05%
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
ECCN Code EAR99
Temperature Coefficient 3ppm/°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 1.27mm
Base Part Number REF5040
Pin Count 8
Number of Outputs 1
Output Voltage 4.096V
Output Type Fixed
Max Output Current 10mA
Supply Voltage-Min (Vsup) 2.7V
Trim/Adjustable Output YES
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Operating Supply Current 1.2mA
Voltage - Input 4.296V~18V
Nominal Supply Current 800μA
Quiescent Current 800μA
Max Output Voltage 4.096V
Min Input Voltage 4.296V
Max Input Voltage 18V
Reference Voltage 4.096V
Reference Type Series
Min Output Voltage 4.096V
Temp Coef of Voltage-Max 3 ppm/°C
Noise - 0.1Hz to 10Hz 3μVp-p
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
