REF5025IDG4
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 REF5025 Tube ACTIVE (Last Updated: 2days ago) voltage reference device 1.2mA 18V 3muVp-p 3ppm/C
PDF
/
Buying Options
Total Price: USD $6.34
Unit Price: USD $6.335155
≥1 USD $6.335155
≥10 USD $5.976561
≥100 USD $5.638263
≥500 USD $5.319123
≥1000 USD $5.018034
Inventory: 1564
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Noise - 0.1Hz to 10Hz 3μVp-p
Temp Coef of Voltage-Max 3 ppm/°C
Reference Type Series
Reference Voltage 2.5V
Max Input Voltage 18V
Min Input Voltage 2.7V
Max Output Voltage 2.5V
Current - Supply 1.2mA
Quiescent Current 1mA
Nominal Supply Current 800μA
Voltage - Input 2.7V~18V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Number of Channels 1
Max Output Current 10mA
Output Type Fixed
Output Voltage 2.5V
Number of Outputs 1
Pin Count 8
Base Part Number REF5025
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 3ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Tolerance ±0.05%
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Weight 75.891673mg
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
