REF3233AMDBVREP
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 REF3233 Tape & Reel (TR) Nickel/Palladium/Gold (Ni/Pd/Au) voltage reference device 10mA 5.5V 63muVrms 40ppm/C
PDF
/
Inventory: 1903
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 2.9mm
Height Seated (Max) 1.45mm
Technical
Noise - 10Hz to 10kHz 63μVrms
Noise - 0.1Hz to 10Hz 43μVp-p
Temp Coef of Voltage-Max 40 ppm/°C
Min Output Voltage 3.3V
Reference Type Series
Max Input Voltage 7.5V
Min Input Voltage 3.35V
Max Output Voltage 3.3V
Quiescent Current 100μA
Nominal Supply Current 100μA
Voltage - Input 3.35V~5.5V
Operating Supply Current 120μA
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Supply Voltage-Max (Vsup) 5.5V
Max Output Current 10mA
Output Type Fixed
Output Voltage 3.3V
Number of Outputs 1
Pin Count 6
Base Part Number REF3233
Terminal Pitch 0.95mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Voltage References
HTS Code 8542.39.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 40ppm/°C
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Discontinued
Pbfree Code yes
JESD-609 Code e4
Tolerance ±0.2%
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C TA
Physical
Number of Pins 6
Surface Mount YES
Package / Case SOT-23-6
Mounting Type Surface Mount
