REF3133AIDBZR
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 REF3133 Tape & Reel (TR) ACTIVE (Last Updated: 3days ago) voltage reference device 10mA 5.5V 63muVrms 20ppm/C
PDF
/
Buying Options
Total Price: USD $1.16
Unit Price: USD $1.1552
≥1 USD $1.1552
≥10 USD $0.9481
≥100 USD $0.9177
≥500 USD $0.88825
≥1000 USD $0.8588
≥3000 USD $0.77045
Inventory: 50057
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 1.3mm
Length 2.92mm
Height 1.22mm
Technical
Noise - 10Hz to 10kHz 63μVrms
Noise - 0.1Hz to 10Hz 43μVp-p
Temp Coef of Voltage-Max 20 ppm/°C
Min Output Voltage 3.3V
Reference Type Series
Max Input Voltage 5.5V
Min Input Voltage 3.35V
Max Output Voltage 3.3V
Quiescent Current 115μA
Max Supply Current 100μA
Nominal Supply Current 100μA
Voltage - Input 3.35V~5.5V
Operating Supply Current 135μA
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Number of Channels 1
Max Output Current 10mA
Output Type Fixed
Output Voltage 3.3V
Number of Outputs 1
Pin Count 3
Base Part Number REF3133
Terminal Pitch 0.96mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Voltage References
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 20ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Tolerance ±0.2%
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 3
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
