REF3112AQDBZRQ1
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 REF3112 Tape & Reel (TR) ACTIVE (Last Updated: 4days ago) voltage reference device 10mA 5.5V 24muVrms 20ppm/C
PDF
/
Buying Options
Total Price: USD $3.3
Unit Price: USD $3.3
≥1 USD $3.3
≥10 USD $2.96384
≥100 USD $2.801568
≥500 USD $2.428184
≥1000 USD $2.303629
≥3000 USD $2.06705
Inventory: 1450
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1mm
Width 1.3mm
Length 2.92mm
Height 1.22mm
Technical
Noise - 10Hz to 10kHz 24μVrms
Noise - 0.1Hz to 10Hz 17μVp-p
Temp Coef of Voltage-Max 20 ppm/°C
Output Voltage-Max 1.2525V
Reference Type Series
Voltage - Output (Min/Fixed) 1.25V
Current - Supply 135μA
Current - Output 10mA
Voltage - Input 1.8V~5.5V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Supply Voltage-Min (Vsup) 1.8V
Supply Voltage-Max (Vsup) 5.5V
Output Type Fixed
Output Voltage 1.25V
Number of Outputs 1
Base Part Number REF3112
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.95mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 20ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Tolerance ±0.2%
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 3
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
