REF3030AIDBZRG4
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Lead Free GULL WING ROHS3Compliant Series Voltage Reference IC 1.22mm ±0.2% 75ppm/C 94muVrms
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.3496
≥1 USD $0.3496
≥10 USD $0.2869
≥100 USD $0.2774
≥500 USD $0.26885
≥1000 USD $0.2603
Inventory: 297598
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Number of Pins 3
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Tolerance ±0.2%
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient 75ppm/°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Voltage References
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.96mm
Base Part Number REF3030
Pin Count 3
Number of Outputs 1
Output Voltage 3V
Output Type Fixed
Max Output Current 25mA
Trim/Adjustable Output NO
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Operating Supply Current 50μA
Voltage - Input 3.05V~5.5V
Nominal Supply Current 42μA
Max Supply Current 50μA
Quiescent Current 42μA
Min Input Voltage 3.001V
Max Input Voltage 5.5V
Reference Voltage 3V
Reference Type Series
Min Output Voltage 3V
Temp Coef of Voltage-Max 75 ppm/°C
Noise - 0.1Hz to 10Hz 33μVp-p
Noise - 10Hz to 10kHz 94μVrms
Dimensions
Height 1.22mm
Length 2.92mm
Width 1.3mm
Thickness 1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
