REF3012AIDBZRG4
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 REF3012 Tape & Reel (TR) ACTIVE (Last Updated: 2days ago) voltage reference device 25mA 5.5V 42muVrms 75ppm/C
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.3496
≥1 USD $0.3496
≥10 USD $0.2869
≥100 USD $0.2774
≥500 USD $0.26885
≥1000 USD $0.2603
Inventory: 55050
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1mm
Width 1.3mm
Length 2.92mm
Height 1.22mm
Technical
Noise - 10Hz to 10kHz 42μVrms
Noise - 0.1Hz to 10Hz 14μVp-p
Temp Coef of Voltage-Max 75 ppm/°C
Min Output Voltage 1.25V
Reference Type Series
Reference Voltage 1.25V
Max Input Voltage 5.5V
Min Input Voltage 1.8V
Max Output Voltage 1.25V
Quiescent Current 42μA
Max Supply Current 50μA
Voltage - Input 1.8V~5.5V
Operating Supply Current 50μA
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Max Output Current 25mA
Output Type Fixed
Output Voltage 1.25V
Number of Outputs 1
Pin Count 3
Base Part Number REF3012
Terminal Pitch 0.96mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Voltage References
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 75ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Tolerance ±0.2%
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Weight 1.437803g
Number of Pins 3
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
