LT1004CPW-2-5
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Lead Free GULL WING ROHS3Compliant voltage reference device 39.008944mg ±0.8% 0C~70C TA 120muVrms
PDF
/
Inventory: 4629
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Number of Pins 8
Weight 39.008944mg
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Tolerance ±0.8%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Temperature Coefficient 20ppm/°C Typical
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LT1004
Pin Count 8
Number of Outputs 1
Qualification Status Not Qualified
Output Voltage 2.5V
Output Type Fixed
Number of Channels 1
Trim/Adjustable Output NO
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Current - Output 20mA
Reference Type Shunt
Current - Cathode 20μA
Noise - 10Hz to 10kHz 120μVrms
Dimensions
Length 4.4mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
