LM431CIM3
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 LM431 Tape & Reel (TR) NRND (Last Updated: 1day ago) voltage reference device 1mA 37V 97ppm/C -0.6% +0.4%
PDF
/
Buying Options
Total Price: USD $1.32
Unit Price: USD $1.32
≥1 USD $1.32
Inventory: 74
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Tolerance -0.6% +0.4%
JESD-609 Code e0
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient 50ppm/°C Typical
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.95mm
Base Part Number LM431
Pin Count 3
Number of Outputs 1
Output Voltage 37V
Output Type Adjustable
Max Output Current 100mA
Supply Voltage-Min (Vsup) 2.44V
Number of Channels 1
Trim/Adjustable Output YES
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Current - Output 100mA
Max Output Voltage 37V
Voltage - Output (Min/Fixed) 2.5V
Max Input Voltage 37V
Reference Voltage 36V
Reference Type Shunt
Temp Coef of Voltage-Max 97 ppm/°C
Current - Cathode 1mA
Dimensions
Height 1.22mm
Length 2.92mm
Width 1.3mm
Thickness 1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
