LM431AIMX
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Lead Free GULL WING Non-RoHS Compliant Shunt Voltage Reference IC 4.9mm ±2.2% 54.509ppm/C 37V
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.2024
≥1 USD $0.2024
Inventory: 2753
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Current - Cathode 1mA
Temp Coef of Voltage-Max 54.509 ppm/°C
Min Output Voltage 2.495V
Reference Type Shunt
Max Input Voltage 37V
Max Output Voltage 37V
Current - Output 100mA
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Number of Channels 1
Max Output Current 100mA
Output Type Adjustable
Output Voltage 37V
Number of Outputs 1
Pin Count 8
Base Part Number LM431
Number of Functions 1
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Voltage References
Terminal Finish Tin/Lead (Sn/Pb)
Temperature Coefficient 50ppm/°C Typical
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Tolerance ±2.2%
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
