LM4130BIM5X-4.1
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 LM4130 Tape & Reel (TR) Series voltage reference device 20mA 5.5V 150muVp-p 20ppm/C
PDF
/
Inventory: 8571
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Tolerance ±0.2%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Temperature Coefficient 20ppm/°C
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.953mm
Reach Compliance Code unknown
Base Part Number LM4130
Pin Count 5
JESD-30 Code R-PDSO-G5
Number of Outputs 1
Output Voltage 4.096V
Output Type Fixed
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.596V
Number of Channels 1
Trim/Adjustable Output NO
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Voltage - Input 4.496V~6V
Current - Output 20mA
Quiescent Current 75μA
Current - Supply 90μA
Reference Type Series
Temp Coef of Voltage-Max 20 ppm/°C
Noise - 0.1Hz to 10Hz 150μVp-p
Dimensions
Length 2.92mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
