LM4128CQ1MF3.0/NOPB
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 LM4128 Tape & Reel (TR) ACTIVE (Last Updated: 6days ago) voltage reference device 100muA 6V 285muVp-p -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $2.51
Unit Price: USD $2.508
≥1 USD $2.508
≥10 USD $2.25104
≥100 USD $2.12784
≥500 USD $1.84404
≥1000 USD $1.74951
≥3000 USD $1.569832
Inventory: 992
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
Tolerance ±0.5%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Temperature Coefficient 100ppm/°C
Terminal Finish Matte Tin (Sn)
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Base Part Number LM4128
Number of Outputs 1
Output Voltage 3V
Output Type Fixed
Max Output Current 20mA
Number of Channels 1
Trim/Adjustable Output NO
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Voltage - Input 3.4V~5.5V
Nominal Supply Current 60μA
Quiescent Current 100μA
Current - Supply 100μA
Max Output Voltage 3V
Min Input Voltage 2.2V
Max Input Voltage 6V
Reference Type Series
Noise - 0.1Hz to 10Hz 285μVp-p
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
