LM4050QAIM3X5.0/NOPB
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Lead Free GULL WING ROHS3Compliant Shunt Voltage Reference IC 2.92mm ±0.5% 1.12mm 50ppm/C
PDF
/
Inventory: 8993
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 1.3mm
Length 2.92mm
Height Seated (Max) 1.12mm
Technical
Noise - 10Hz to 10kHz 93μVrms
Current - Cathode 80μA
Temp Coef of Voltage-Max 50 ppm/°C
Reference Type Shunt
Current - Output 15mA
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Output Type Fixed
Output Voltage 5V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PDSO-G3
Base Part Number LM4050
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.95mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Voltage References
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Temperature Coefficient 50ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Tolerance ±0.5%
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
