LM4040C25ILP
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 LM4040 Bulk ACTIVE (Last Updated: 5days ago) voltage reference device 80muA 2.5V 35muVrms 150ppm/C
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.53675
≥1 USD $0.53675
≥10 USD $0.4408
≥100 USD $0.42655
≥500 USD $0.41325
≥1000 USD $0.399
Inventory: 1440
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 3.6mm
Width 4.3mm
Length 4.3mm
Height 5.34mm
Technical
Noise - 10Hz to 10kHz 35μVrms
Current - Cathode 80μA
Temp Coef of Voltage-Max 150 ppm/°C
Min Output Voltage 2.5V
Reference Type Shunt
Reference Voltage 2.5V
Max Output Voltage 2.5V
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Max Output Current 15mA
Output Type Fixed
Output Voltage 2.5V
Number of Outputs 1
Pin Count 3
Base Part Number LM4040
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Terminal Position BOTTOM
Technology BIPOLAR
Subcategory Voltage References
Terminal Finish Matte Tin (Sn)
Temperature Coefficient 100ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±0.5%
Packaging Bulk
Operating Temperature -40°C~85°C TA
Physical
Weight 213.188414mg
Number of Pins 3
Surface Mount NO
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
