LM136-5.0-MW8

Texas Instruments
RoHS
RoHS RoHS compliant
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description Lead Free NO LEAD ROHS3Compliant MIL-STD-883 voltage reference device ±2% -55C~125C TA 6V 600muA
PDF
/
Inventory: 5126
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Technical

Current - Cathode 600μA
Screening Level MIL-STD-883
Reference Type Shunt
Current - Output 10mA
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Supply Voltage-Min (Vsup) 4V
Supply Voltage-Max (Vsup) 6V
Output Type Fixed
Output Voltage 5V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XUUC-N8
Base Part Number LM136
Number of Functions 1
Terminal Form NO LEAD
Terminal Position UPPER
Technology BIPOLAR
Additional Feature ADJUSTABLE FROM 4V TO 6V
Number of Terminations 8
Part Status Active
Tolerance ±2%
Operating Temperature -55°C~125°C TA

Physical

Number of Pins 0
Surface Mount YES

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 26 Weeks
