ATL431LIAQDQNR
RoHS
RoHS compliant
RoHS compliantPackage 4-XDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
S-PDSO-N4 ATL431 4-XDFN Exposed Pad Nickel/Palladium/Gold (Ni/Pd/Au) voltage reference device 80muA 2.5V 66ppm/C 0.4mm
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.4136
≥1 USD $0.4136
≥10 USD $0.35464
≥100 USD $0.331232
≥500 USD $0.26488
≥1000 USD $0.245978
≥3000 USD $0.20812
Inventory: 1186
Minimum: 1
-
+
Technical Details
Technical
Tolerance ±1%
Operating Temperature -40°C~125°C TA
Current - Cathode 80μA
Temp Coef of Voltage-Max 66 ppm/°C
Output Voltage-Min 2.475V
Voltage - Output (Max) 36V
Reference Type Shunt
Voltage - Output (Min/Fixed) 2.5V
Current - Output 15mA
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Output Type Adjustable
Output Voltage 2.5V
Number of Outputs 1
JESD-30 Code S-PDSO-N4
Base Part Number ATL431
Terminal Pitch 0.65mm
Number of Functions 1
Terminal Form NO LEAD
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Physical
Surface Mount YES
Package / Case 4-XDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 1mm
Length 1mm
Height Seated (Max) 0.4mm
