ATL431LIAQDBZR
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
R-PDSO-G3 ATL431 Cut Tape (CT) Nickel/Palladium/Gold (Ni/Pd/Au) voltage reference device 100muA 36V 66ppm/C 1.12mm
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.2728
≥1 USD $0.2728
≥10 USD $0.23672
≥100 USD $0.221408
≥500 USD $0.177056
≥1000 USD $0.164419
≥3000 USD $0.139128
Inventory: 10303
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 1.3mm
Length 2.92mm
Height Seated (Max) 1.12mm
Technical
Current - Cathode 100μA
Temp Coef of Voltage-Max 66 ppm/°C
Output Voltage-Min 2.475V
Voltage - Output (Max) 36V
Reference Type Shunt
Voltage - Output (Min/Fixed) 2.5V
Current - Output 15mA
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Supply Voltage-Min (Vsup) 2.475V
Supply Voltage-Max (Vsup) 36V
Output Type Adjustable
Output Voltage 2.5V
Number of Outputs 1
JESD-30 Code R-PDSO-G3
Base Part Number ATL431
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code compliant
Terminal Pitch 0.95mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Tolerance ±1%
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
