5962-9167301QEA
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
VOLTAGE-MODE THROUGH-HOLE RoHS Compliant MIL-PRF-38535Class Q voltage reference device 58kHz 19.43mm 5.08mm 125C
PDF
/
Inventory: 2862
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount NO
Technical
JESD-609 Code e0
Screening Level MIL-PRF-38535 Class Q
Switching Frequency-Max 58kHz
Switcher Configuration BUCK
Supply Current-Max (Isup) 12mA
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 40V
Output Current-Max 3A
Control Mode VOLTAGE-MODE
Input Voltage (Min) 15V
Analog IC - Other Type SWITCHING REGULATOR
Temperature Grade MILITARY
Input Voltage-Nom 25V
Output Voltage 12V
Operating Temperature (Min) -55°C
Operating Temperature (Max) 125°C
Qualification Status Not Qualified
JESD-30 Code R-GDIP-T16
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form THROUGH-HOLE
Terminal Position DUAL
Technology BIPOLAR
Subcategory Switching Regulator or Controllers
HTS Code 8542.39.00.01
Additional Feature CAN ALSO CONFIGURED AS BUCK BOOST REGULATOR
Terminal Finish TIN LEAD
ECCN Code EAR99
Number of Terminations 16
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7.62mm
Length 19.43mm
Height Seated (Max) 5.08mm
