RoHS
RoHS RoHS compliant
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description EAR99 TS822 Cut Tape (CT) Tin (Sn) voltage reference device 60muA 2.5V 100ppm/C ±2%
PDF
/
Inventory: 3903
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Number of Pins 3

Technical

Operating Temperature -40°C~85°C TA
Packaging Cut Tape (CT)
Tolerance ±2%
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient 100ppm/°C
Terminal Finish Tin (Sn)
Terminal Position BOTTOM
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TS822
Pin Count 3
Number of Outputs 1
Qualification Status Not Qualified
Output Voltage 2.5V
Output Type Fixed
Trim/Adjustable Output NO
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Current - Output 15mA
Reference Type Shunt
Min Output Voltage 2.5V
Temp Coef of Voltage-Max 100 ppm/°C
Current - Cathode 60μA

Compliance

RoHS Status ROHS3 Compliant
Lead Free Contains Lead
