TS822AIZT
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 TS822 Tape & Reel (TR) TIN voltage reference device 60muA 2.5V 100ppm/C ±1%
PDF
/
Inventory: 5806
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TS822
Pin Count 3
Number of Outputs 1
Qualification Status Not Qualified
Output Voltage 2.5V
Output Type Fixed
Trim/Adjustable Output NO
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Current - Output 15mA
Reference Type Shunt
Min Output Voltage 2.5V
Temp Coef of Voltage-Max 100 ppm/°C
Current - Cathode 60μA
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form WIRE
Terminal Position BOTTOM
Terminal Finish TIN
Temperature Coefficient 100ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Tolerance ±1%
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
Mount Through Hole
