TL431AIZ
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 TL431 Bulk ACTIVE (Last Updated: 7months ago) voltage reference device 700muA 37V 82.924ppm/C ±1%
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.308
≥1 USD $0.308
≥10 USD $0.26224
≥100 USD $0.24464
≥500 USD $0.195624
≥1000 USD $0.181632
≥3000 USD $0.153683
Inventory: 1527
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Number of Pins 3
Weight 4.535924g
Technical
Operating Temperature -40°C~105°C TA
Packaging Bulk
Tolerance ±1%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient 100 ppm/°C
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Voltage References
Technology BIPOLAR
Terminal Position BOTTOM
Number of Functions 1
Base Part Number TL431
Pin Count 3
Number of Outputs 1
Output Voltage 36V
Output Type Adjustable
Max Output Current 100mA
Number of Channels 1
Trim/Adjustable Output YES
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Nominal Supply Current 1mA
Accuracy 1 %
Max Output Voltage 36V
Max Input Voltage 37V
Reference Voltage 2.495V
Reference Type Shunt
Min Output Voltage 2.495V
Temp Coef of Voltage-Max 82.924 ppm/°C
Current - Cathode 700μA
Dimensions
Height 4.4mm
Length 4.7mm
Width 3.7mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
