TL1431ID
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 TL1431 Tube Nickel/Palladium/Gold (Ni/Pd/Au) voltage reference device 1mA 37V -40C~105C TA ±0.4%
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.27645
≥1 USD $0.27645
≥10 USD $0.22705
≥100 USD $0.2204
≥500 USD $0.2128
≥1000 USD $0.20615
Inventory: 20775
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4mm
Length 5mm
Height 1.25mm
Technical
Current - Cathode 1mA
Min Output Voltage 2.5V
Reference Type Shunt
Reference Voltage 36V
Max Input Voltage 37V
Max Output Voltage 36V
Nominal Supply Current 2.5μA
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Number of Channels 1
Max Output Current 100mA
Output Type Adjustable
Output Voltage 36V
Number of Outputs 1
Pin Count 8
Base Part Number TL1431
Time@Peak Reflow Temperature-Max (s) 30
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Voltage References
Additional Feature THE OUTPUT VOLTAGE MAY BE SET TO ANY VALUE BETWEEN 2.5V AND 36V WITH TWO EXTERNAL RESISTORS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 100ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Tolerance ±0.4%
Packaging Tube
Operating Temperature -40°C~105°C TA
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
