SP813LEP
RoHS
/
Package DIP
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
THROUGH-HOLE Non-RoHS Compliant DUAL CMOS voltage reference device 9.27mm 5.33mm 85C 5.5V
PDF
/
Buying Options
Total Price: USD $5.36
Unit Price: USD $5.36465
≥1 USD $5.36465
≥10 USD $4.40135
≥100 USD $4.26455
≥500 USD $4.1268
≥1000 USD $3.98905
Inventory: 8004
Minimum: 1
-
+
Technical Details
Physical
Package / Case DIP
Surface Mount NO
Technical
JESD-609 Code e0
Number of Terminations 8
Terminal Finish TIN LEAD
Additional Feature RESET THRESHOLD VOLTAGE IS 4.65V; MANUAL RESET INPUT
Subcategory Power Management Circuits
Technology CMOS
Terminal Position DUAL
Terminal Form THROUGH-HOLE
Peak Reflow Temperature (Cel) NOT APPLICABLE
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 1V
Number of Channels 1
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Adjustable Threshold NO
Supply Current-Max (Isup) 0.06mA
Dimensions
Height Seated (Max) 5.33mm
Length 9.27mm
Width 3mm
Compliance
RoHS Status Non-RoHS Compliant
