SP6831EK/TR
RoHS
/
Package SOT
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
GULL WING Non-RoHS Compliant DUAL DOUBLER INVERTER voltage reference device 200kHz 2.95mm 1.45mm 85C
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4028
≥1 USD $0.4028
≥10 USD $0.3306
≥100 USD $0.32015
≥500 USD $0.31065
≥1000 USD $0.3002
Inventory: 2708
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 1.625mm
Length 2.95mm
Height Seated (Max) 1.45mm
Technical
Switching Frequency-Max 200kHz
Switcher Configuration DOUBLER INVERTER
Input Voltage (Max) 5.3V
Output Current-Max 0.05A
Input Voltage (Min) 1.15V
Analog IC - Other Type SWITCHED CAPACITOR CONVERTER
Temperature Grade INDUSTRIAL
Input Voltage-Nom 5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G6
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.95mm
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Terminal Finish TIN LEAD
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e0
Physical
Surface Mount YES
Package / Case SOT
