REF43GP
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
R-PDIP-T8 Tray TIN LEAD INDUSTRIAL voltage reference device 40V 25ppm/C 4.57mm 9.27mm
PDF
/
Buying Options
Total Price: USD $5.77
Unit Price: USD $5.7728
≥1 USD $5.7728
Inventory: 4565
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Length 9.27mm
Height Seated (Max) 4.57mm
Technical
Temp Coef of Voltage-Max 25 ppm/°C
Output Voltage-Min 2.495V
Output Voltage-Max 2.505V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 40V
Output Voltage 2.5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Outputs 1
JESD-30 Code R-PDIP-T8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Position DUAL
Technology BIPOLAR
Terminal Finish TIN LEAD
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tray
Physical
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
