REF01EJ
RoHS
/
Package TO-99-8 Metal Can
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
O-MBCY-W8 Bulk TIN LEAD OUTPUT VOLTAGE ADJUSTABLE 3PERCENT voltage reference device 40V 8.5ppm/C
PDF
/
Buying Options
Total Price: USD $14.88
Unit Price: USD $14.8808
≥1 USD $14.8808
Inventory: 1109
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-99-8 Metal Can
Surface Mount NO
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Terminal Finish TIN LEAD
Additional Feature OUTPUT VOLTAGE ADJUSTABLE 3 PERCENT
Technology BIPOLAR
Terminal Position BOTTOM
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT APPLICABLE
Number of Functions 1
Supply Voltage 15V
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Pin Count 8
JESD-30 Code O-MBCY-W8
Number of Outputs 1
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Output Voltage 10V
Supply Voltage-Max (Vsup) 40V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 12V
Trim/Adjustable Output YES
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Output Voltage-Max 10.03V
Output Voltage-Min 9.97V
Temp Coef of Voltage-Max 8.5 ppm/°C
Compliance
RoHS Status Non-RoHS Compliant
