MAX6104EUR-T
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount GULL WING Non-RoHS Compliant DUAL Series Voltage Reference IC 2.92mm ?±0.4% 1.12mm 75ppm/C
PDF
/
Buying Options
Total Price: USD $0.04
Unit Price: USD $0.04127
≥1 USD $0.04127
≥10 USD $0.038935
≥100 USD $0.036731
≥500 USD $0.034653
≥1000 USD $0.032694
Inventory: 1245
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Technical
Operating Temperature -40?°C~85?°C TA
Packaging Tape & Reel (TR)
Tolerance ?±0.4%
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Temperature Coefficient 75ppm/?°C
Terminal Finish TIN LEAD
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.95mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code R-PDSO-G3
Number of Outputs 1
Output Voltage 4.096V
Output Type Fixed
Supply Voltage-Max (Vsup) 12.6V
Supply Voltage-Min (Vsup) 4.296V
Trim/Adjustable Output NO
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Voltage - Input 4.296V~12.6V
Current - Output 5mA
Current - Supply 125??A
Voltage - Output (Min/Fixed) 4.096V
Reference Type Series
Output Voltage-Max 4.112V
Temp Coef of Voltage-Max 75 ppm/?°C
Noise - 0.1Hz to 10Hz 50??Vp-p
Noise - 10Hz to 10kHz 50??Vrms
Dimensions
Height Seated (Max) 1.12mm
Length 2.92mm
Width 1.3mm
Compliance
RoHS Status Non-RoHS Compliant
