LM385M3X-2.5
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
R-PDSO-G3 Tape & Reel (TR) TIN LEAD Shunt voltage reference device 15muA 2.5V 120muVrms 150ppm/C
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.78945
≥1 USD $0.78945
≥10 USD $0.6479
≥100 USD $0.62795
≥500 USD $0.608
≥1000 USD $0.5871
Inventory: 56336
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 1.4mm
Length 2.92mm
Height Seated (Max) 1.12mm
Technical
Noise - 10Hz to 10kHz 120μVrms
Current - Cathode 15μA
Temp Coef of Voltage-Max 150 ppm/°C
Output Voltage-Min 2.425V
Output Voltage-Max 2.575V
Reference Type Shunt
Voltage - Output (Min/Fixed) 2.5V
Current - Output 20mA
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Output Type Fixed
Output Voltage 2.5V
Number of Outputs 1
JESD-30 Code R-PDSO-G3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.95mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Terminal Finish TIN LEAD
Temperature Coefficient 150ppm/°C
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e0
Tolerance ±3%
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
