ISL21009CFB841Z
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
R-PDSO-G8 Tube MATTE TIN Series voltage reference device 7mA 16.5V 22muVrms 5ppm/C
PDF
/
Buying Options
Total Price: USD $7.17
Unit Price: USD $7.172
≥1 USD $7.172
Inventory: 1342
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Noise - 10Hz to 10kHz 22μVrms
Noise - 0.1Hz to 10Hz 4.5μVp-p
Temp Coef of Voltage-Max 5 ppm/°C
Output Voltage-Max 4.097V
Reference Type Series
Voltage - Output (Min/Fixed) 4.096V
Current - Supply 180μA
Current - Output 7mA
Voltage - Input 4.5V~16.5V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 16.5V
Output Type Fixed
Output Voltage 4.096V
Number of Outputs 1
JESD-30 Code R-PDSO-G8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Terminal Finish MATTE TIN
Temperature Coefficient 5ppm/°C
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Tolerance ±0.08%
Series FGA?
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
