ADR280ART-R2
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
R-PDSO-G3 Tape & Reel (TR) TIN LEAD INDUSTRIAL voltage reference device 5.5V 40ppm/C 1.12mm 2.9mm
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.14795
≥1 USD $2.14795
≥10 USD $1.7632
≥100 USD $1.7081
≥500 USD $1.653
≥1000 USD $1.5979
Inventory: 43632
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 1.3mm
Length 2.9mm
Height Seated (Max) 1.12mm
Technical
Temp Coef of Voltage-Max 40 ppm/°C
Output Voltage-Min 1.195V
Output Voltage-Max 1.205V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Supply Voltage-Min (Vsup) 2.55V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 5.5V
Output Voltage 1.2V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Outputs 1
JESD-30 Code R-PDSO-G3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Reach Compliance Code unknown
Terminal Pitch 0.95mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT APPLICABLE
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Terminal Finish TIN LEAD
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
