TL431ACLPX
RoHS
/
Package TO-226-2, TO-92-2 (TO-226AC) (Formed Leads)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
IC VREF SHUNT 36V 1% TO92-3
PDF
/
Buying Options
Total Price: USD $0.07
Unit Price: USD $0.065753
≥1 USD $0.065753
≥200 USD $0.025446
≥500 USD $0.024552
≥1000 USD $0.024109
Inventory: 1359
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Current - Cathode 1mA
Reference Type Shunt
Reference Voltage 2.5V
Max Input Voltage 37V
Voltage - Output (Min/Fixed) 2.495V
Max Output Voltage 36V
Number of Channels 1
Output Type Adjustable
Output Voltage 36V
Base Part Number TL431
Current Rating 100mA
Voltage - Rated 36V
Temperature Coefficient 50ppm/°C Typical
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±1%
Packaging Tape & Reel (TR)
Operating Temperature -25°C~85°C TA
Physical
Weight 240mg
Number of Pins 3
Package / Case TO-226-2, TO-92-2 (TO-226AC) (Formed Leads)
Mounting Type Through Hole
Mount Through Hole
