TL431ACDR2
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Contains Lead GULL WING Non-RoHS Compliant Shunt Voltage Reference IC 4.9mm 1.5W ±1% 0C~70C TA
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.41515
≥1 USD $0.41515
≥10 USD $0.34105
≥100 USD $0.32965
≥500 USD $0.3192
≥1000 USD $0.30875
Inventory: 17106
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature 0°C~70°C TA
Packaging Tape & Reel (TR)
Published 2005
Tolerance ±1%
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Temperature Coefficient 50ppm/°C Typical
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number TL431
Pin Count 8
Number of Outputs 1
Qualification Status Not Qualified
Output Voltage 36V
Output Type Adjustable
Number of Channels 1
Current - Cathode 1mA
Reference Type Shunt
Max Input Voltage 37V
Voltage - Output (Min/Fixed) 2.495V
Max Output Voltage 36V
Current - Output 100mA
Power Dissipation 1.5W
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Voltage 36V
Trim/Adjustable Output YES
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 4.9mm
