REF3040TB-GT3
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Lead Free GULL WING RoHS Compliant Series Voltage Reference IC 2.92mm ±0.2% 888ppm/C 50muVp-p
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.21255
≥1 USD $2.21255
≥10 USD $1.81545
≥100 USD $1.75845
≥500 USD $1.70145
≥1000 USD $1.6454
Inventory: 7991
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LIFETIME (Last Updated: 4 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Technical
Operating Temperature -40°C~85°C TA
Noise - 0.1Hz to 10Hz 50μVp-p
Temp Coef of Voltage-Max 888 ppm/°C
Reference Type Series
Halogen Free Halogen Free
Max Input Voltage 6.5V
Current - Supply 30μA
Quiescent Current 30μA
Voltage - Input 2.7V~5.5V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output YES
Number of Channels 1
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 5.5V
Max Output Current 10mA
Output Type Fixed
Output Voltage 4.096V
Number of Outputs 1
Pin Count 3
Base Part Number REF3040
Terminal Pitch 0.95mm
Supply Voltage 3V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 50ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Tolerance ±0.2%
Published 2011
Packaging Tape & Reel (TR)
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 2.92mm
