CAT8900D204TBGT3
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Lead Free GULL WING RoHS Compliant Series Voltage Reference IC 1.12mm ±0.24% -40C~85C TA 50muVp-p
PDF
/
Buying Options
Total Price: USD $1.62
Unit Price: USD $1.6226
≥1 USD $1.6226
≥10 USD $1.3319
≥100 USD $1.2901
≥500 USD $1.2483
≥1000 USD $1.2065
Inventory: 7791
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 1.4mm
Length 3.04mm
Height 1.12mm
Technical
Noise - 0.1Hz to 10Hz 50μVp-p
Reference Type Series
Reference Voltage 2.048V
Halogen Free Halogen Free
Max Input Voltage 3.3V
Min Input Voltage 1.024V
Max Output Voltage 2.048V
Quiescent Current 800nA
Nominal Supply Current 450nA
Voltage - Input 2.7V~5.5V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Number of Channels 1
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 5.5V
Max Output Current 10mA
Output Type Fixed
Output Voltage 2.048V
Number of Outputs 1
Pin Count 3
Base Part Number CAT8900
Current Rating 10mA
Terminal Pitch 0.95mm
Supply Voltage 3V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Temperature Coefficient 50ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Tolerance ±0.24%
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 day ago)
