MAX674CPA+
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 MAX674 Tube 2004 voltage reference device 10mA 33V 20muVp-p 12ppm/C
PDF
/
Buying Options
Total Price: USD $61.41
Unit Price: USD $61.40515
≥1 USD $61.40515
≥10 USD $50.38325
≥100 USD $48.8091
≥500 USD $47.234
≥1000 USD $45.65985
Inventory: 1230
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Published 2004
Tolerance ±0.15%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Temperature Coefficient 12ppm/°C
Terminal Finish Matte Tin (Sn)
HTS Code 8542.39.00.01
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 15V
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX674
Pin Count 8
JESD-30 Code R-PDIP-T8
Number of Outputs 1
Qualification Status Not Qualified
Output Voltage 10V
Output Type Fixed
Supply Voltage-Max (Vsup) 33V
Supply Voltage-Min (Vsup) 13V
Trim/Adjustable Output YES
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Voltage - Input 13V~33V
Current - Output 10mA
Current - Supply 1.4mA
Voltage - Output (Min/Fixed) 10V
Reference Type Series
Output Voltage-Max 10.015V
Temp Coef of Voltage-Max 12 ppm/°C
Noise - 0.1Hz to 10Hz 20μVp-p
Dimensions
Height Seated (Max) 4.572mm
Length 9.375mm
Width 7.62mm
Compliance
RoHS Status ROHS3 Compliant
