MAX6250BMJA
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
THROUGH-HOLE Non-RoHS Compliant DUAL BIPOLAR voltage reference device 2.54mm 5.08mm 8ppm/C 36V
PDF
/
Inventory: 9166
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8542.39.00.01
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Terminal Form THROUGH-HOLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 10V
Terminal Pitch 2.54mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
JESD-30 Code R-GDIP-T8
Number of Outputs 1
Qualification Status Not Qualified
Operating Temperature (Max) 125°C
Operating Temperature (Min) -55°C
Output Voltage 5V
Supply Voltage-Max (Vsup) 36V
Temperature Grade MILITARY
Supply Voltage-Min (Vsup) 8V
Trim/Adjustable Output YES
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Supply Current-Max (Isup) 3.3mA
Voltage Tolerance-Max 0.1%
Output Voltage-Max 5.005V
Output Voltage-Min 4.995V
Temp Coef of Voltage-Max 8 ppm/°C
Number of Terminations 8
Pbfree Code no
JESD-609 Code e0
Dimensions
Height Seated (Max) 5.08mm
Width 7.62mm
Physical
Surface Mount NO
Compliance
RoHS Status Non-RoHS Compliant
