MAX6225ACSA
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Contains Lead GULL WING Non-RoHS Compliant Series, Buried Zener Voltage Reference IC 1.5mm ±0.04% 2ppm/C 1.3muVrms
PDF
/
Buying Options
Total Price: USD $6.08
Unit Price: USD $6.08285
≥1 USD $6.08285
≥10 USD $4.9913
≥100 USD $4.8355
≥500 USD $4.6797
≥1000 USD $4.5239
Inventory: 1095
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Published 2001
Tolerance ±0.04%
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Temperature Coefficient 2ppm/°C
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 10V
Base Part Number MAX6225
Pin Count 8
Number of Outputs 1
Output Voltage 2.5V
Output Type Fixed
Max Output Current 15mA
Supply Voltage-Min (Vsup) 8V
Number of Channels 1
Trim/Adjustable Output YES
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Operating Supply Current 3mA
Voltage - Input 8V~36V
Nominal Supply Current 3mA
Max Supply Current 3mA
Quiescent Current 3mA
Max Output Voltage 2.501V
Min Input Voltage 8V
Max Input Voltage 36V
Reference Voltage 2.5V
Reference Type Series, Buried Zener
Min Output Voltage 2.5V
Temp Coef of Voltage-Max 2 ppm/°C
Noise - 0.1Hz to 10Hz 1.5μVp-p
Noise - 10Hz to 10kHz 1.3μVrms
Dimensions
Height 1.5mm
Length 5mm
Width 4mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
