MAX6225ACPA+
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Through Hole Lead Free ROHS3Compliant DUAL Series, Buried Zener Voltage Reference IC 4.45mm ±0.04% 2ppm/C 1.3muVrms
PDF
/
Buying Options
Total Price: USD $27.65
Unit Price: USD $27.64975
≥1 USD $27.64975
≥10 USD $22.68695
≥100 USD $21.97825
≥500 USD $21.2686
≥1000 USD $20.5599
Inventory: 25
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Number of Pins 8
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Published 2001
Tolerance ±0.04%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Temperature Coefficient 2ppm/°C
Terminal Finish Matte Tin (Sn)
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 10V
Terminal Pitch 2.54mm
Base Part Number MAX6225
Pin Count 8
Number of Outputs 1
Output Voltage 2.5V
Output Type Fixed
Max Output Current 15mA
Supply Voltage-Max (Vsup) 36V
Supply Voltage-Min (Vsup) 8V
Trim/Adjustable Output YES
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Operating Supply Current 3mA
Voltage - Input 8V~36V
Max Output Voltage 2.5V
Max Input Voltage 40V
Reference Voltage 2.5V
Reference Type Series, Buried Zener
Min Output Voltage 2.5V
Temp Coef of Voltage-Max 2 ppm/°C
Noise - 0.1Hz to 10Hz 1.5μVp-p
Noise - 10Hz to 10kHz 1.3μVrms
Dimensions
Height 4.45mm
Length 9.91mm
Width 7.87mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
