MAX6104EUR
RoHS
/
Package SOT-23
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount GULL WING RoHS Compliant DUAL voltage reference device 2.8575mm 1.194mm 75ppm/C 12.6V
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.6112
≥1 USD $1.6112
≥10 USD $1.3224
≥100 USD $1.2806
≥500 USD $1.23975
≥1000 USD $1.19795
Inventory: 1555
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 1.2955mm
Length 2.8575mm
Height Seated (Max) 1.194mm
Technical
Temp Coef of Voltage-Max 75 ppm/°C
Voltage Tolerance-Max 0.4%
Max Input Voltage 13.5V
Voltage - Output 4.096V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Supply Voltage-Min (Vsup) 4.296V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 12.6V
Max Output Current 5mA
Output Voltage 4.096V
Number of Outputs 1
Terminal Pitch 0.952mm
Supply Voltage 5V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Voltage References
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn85Pb15)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1
Pbfree Code no
JESD-609 Code e0
Packaging Cut Tape
Physical
Number of Pins 3
Package / Case SOT-23
Mount Surface Mount
