MAX6050BEUR-T
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount Contains Lead GULL WING Non-RoHS Compliant Series Voltage Reference IC 2.92mm ±0.4% -40C~85C TA 240muVrms
PDF
/
Buying Options
Total Price: USD $3.96
Unit Price: USD $3.956018
≥1 USD $3.956018
≥10 USD $3.732085
≥100 USD $3.52084
≥500 USD $3.321549
≥1000 USD $3.133534
Inventory: 1200
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2001
Tolerance ±0.4%
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient 30ppm/°C
Subcategory Voltage References
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.95mm
Base Part Number MAX6050
Pin Count 3
Number of Outputs 1
Output Voltage 5V
Output Type Fixed
Max Output Current 500μA
Supply Voltage-Min (Vsup) 5.2V
Number of Channels 1
Trim/Adjustable Output NO
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Operating Supply Current 35μA
Voltage - Input 5.2V~12.6V
Quiescent Current 35μA
Max Input Voltage 13.5V
Reference Type Series
Min Output Voltage 5V
Noise - 0.1Hz to 10Hz 120μVp-p
Noise - 10Hz to 10kHz 240μVrms
Dimensions
Length 2.92mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
