MAX6041AEUR+
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
GULL WING RoHS Compliant DUAL BIPOLAR voltage reference device 2.8575mm 1.194mm 20ppm/C 12.6V
PDF
/
Buying Options
Total Price: USD $3.31
Unit Price: USD $3.306853
≥1 USD $3.306853
≥10 USD $3.119675
≥100 USD $2.943085
≥500 USD $2.776502
≥1000 USD $2.619338
Inventory: 1358
Minimum: 1
-
+
Technical Details
Physical
Surface Mount YES
Technical
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8542.39.00.01
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.953mm
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) 30
JESD-30 Code R-PDSO-G3
Number of Outputs 1
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Output Voltage 4.096V
Supply Voltage-Max (Vsup) 12.6V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 4.296V
Trim/Adjustable Output NO
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Voltage Tolerance-Max 0.2%
Output Voltage-Max 4.104V
Output Voltage-Min 4.088V
Temp Coef of Voltage-Max 20 ppm/°C
Dimensions
Height Seated (Max) 1.194mm
Length 2.8575mm
Width 1.2955mm
Compliance
RoHS Status RoHS Compliant
