LM4040AIX3-2.5
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
GULL WING Non-RoHS Compliant DUAL BICMOS voltage reference device 2mm 1.1mm 100ppm/C 2.5V
PDF
/
Inventory: 5759
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount YES
Technical
Packaging Cut Tape
JESD-609 Code e0
Pbfree Code no
Moisture Sensitivity Level (MSL) 1
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn85Pb15)
HTS Code 8542.39.00.01
Subcategory Voltage References
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Terminal Pitch 0.65mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 20
Pin Count 3
JESD-30 Code R-PDSO-G3
Number of Outputs 1
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Output Voltage 2.5V
Temperature Grade INDUSTRIAL
Trim/Adjustable Output NO
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Voltage Tolerance-Max 0.1%
Output Voltage-Max 2.519V
Output Voltage-Min 2.481V
Temp Coef of Voltage-Max 100 ppm/°C
Dimensions
Height Seated (Max) 1.1mm
Length 2mm
Width 1.25mm
Compliance
RoHS Status Non-RoHS Compliant
