LTC6655BHLS8-4.096#PBF
RoHS
RoHS compliant
RoHS compliantPackage 8-CLCC
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 LTC6655 Tray Series voltage reference device 5mA 13.2V 0.25ppmp-p 2ppm/C
PDF
/
Buying Options
Total Price: USD $15.36
Unit Price: USD $15.3648
≥1 USD $15.3648
≥10 USD $14.11784
≥100 USD $13.532288
≥500 USD $11.92312
≥1000 USD $11.337955
≥3000 USD $10.60649
Inventory: 1045
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-CLCC
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TA
Packaging Tray
Tolerance ±0.025%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Temperature Coefficient 2ppm/°C
HTS Code 8542.39.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LTC6655
Pin Count 8
JESD-30 Code S-CQCC-N8
Number of Outputs 1
Output Voltage 4.096V
Output Type Fixed
Supply Voltage-Max (Vsup) 13.2V
Supply Voltage-Min (Vsup) 4.296V
Trim/Adjustable Output NO
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Voltage - Input 4.596V~13.2V
Current - Output 5mA
Current - Supply 7.5mA
Voltage - Output (Min/Fixed) 4.096V
Reference Type Series
Output Voltage-Max 4.097024V
Temp Coef of Voltage-Max 2 ppm/°C
Noise - 0.1Hz to 10Hz 0.25ppmp-p
Dimensions
Height Seated (Max) 1.55mm
Length 5mm
Width 5mm
Compliance
RoHS Status ROHS3 Compliant
