LT6656BCS6-5#TRMPBF
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6 Thin, TSOT-23-6
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
EAR99 LT6656 Tape & Reel (TR) 2007 voltage reference device 5mA 18V 140muVrms 20ppm/C
PDF
/
Buying Options
Total Price: USD $4.97
Unit Price: USD $4.972
≥1 USD $4.972
≥10 USD $4.46336
≥100 USD $4.219424
≥500 USD $3.656928
≥1000 USD $3.469418
Inventory: 1195
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-6 Thin, TSOT-23-6
Number of Pins 6
Technical
Operating Temperature 0°C~70°C TA
Packaging Tape & Reel (TR)
Published 2007
Tolerance ±0.1%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Temperature Coefficient 20ppm/°C
Terminal Finish Matte Tin (Sn)
Subcategory Voltage References
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 0.95mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LT6656
Pin Count 6
Number of Outputs 1
Qualification Status Not Qualified
Output Voltage 5V
Output Type Fixed
Number of Channels 1
Trim/Adjustable Output NO
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Voltage - Input 5.5V~18V
Current - Output 5mA
Quiescent Current 1μA
Current - Supply 1.5μA
Max Output Voltage 5V
Min Input Voltage 5.5V
Max Input Voltage 18V
Reference Voltage 5V
Reference Type Series
Temp Coef of Voltage-Max 20 ppm/°C
Noise - 0.1Hz to 10Hz 30ppmp-p
Noise - 10Hz to 10kHz 140μVrms
Dimensions
Length 2.9mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
