LT1790BCS6-1.25#TRPBF

Linear Technology/Analog Devices
RoHS
RoHS RoHS compliant
Package SOT-23-6 Thin, TSOT-23-6
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description EAR99 LT1790 Tape & Reel (TR) Matte Tin (Sn) voltage reference device 5mA 18V 14muVrms 25ppm/C
PDF
/
Buying Options
Total Price: USD $3.53
Unit Price: USD $3.5288
≥1 USD $3.5288
≥10 USD $3.17328
≥100 USD $2.999744
≥500 USD $2.599696
≥1000 USD $2.466429
≥3000 USD $2.213112
Inventory: 1167
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 1.625mm
Length 2.95mm
Height Seated (Max) 1mm

Technical

Noise - 10Hz to 10kHz 14μVrms
Noise - 0.1Hz to 10Hz 10μVp-p
Temp Coef of Voltage-Max 25 ppm/°C
Output Voltage-Max 1.25344V
Reference Type Series
Voltage - Output (Min/Fixed) 1.25V
Current - Supply 75μA
Current - Output 5mA
Voltage - Input 2.6V~18V
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Supply Voltage-Min (Vsup) 2.6V
Supply Voltage-Max (Vsup) 18V
Output Type Fixed
Output Voltage 1.25V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PDSO-G6
Pin Count 6
Base Part Number LT1790
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.95mm
Supply Voltage 2.6V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Voltage References
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Temperature Coefficient 25ppm/°C
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Tolerance ±0.1%
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA

Physical

Surface Mount YES
Package / Case SOT-23-6 Thin, TSOT-23-6
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
